22R SPEEDY SLEEVE TOOL
Installing a speedy sleeve on a 22R Toyota crank can be difficult because of the flywheel pilot flange sticking out of the back of the crank. I used a piece of tool steel, drilled a hole in it then installed a spring and a pin to hold it to the pilot shaft that was turned down and stepped. This makes putting a sleeve on a 22R Toyota crank real easy.

Nick Redenbaugh
Sierra Auto
Modesto, CA
June, 2018
